Lamassu Virtual Device

Virtual Device

It is recommended to follow this directory layout when deploying different Lamassu tools:

$HOME/
     ├── lamassu-compose
     ├── lamassu-virtual-device
     └── lamassu-virtual-dms
Make sure to define the following variable with the absolute path

LAMASSU_COMPOSE_DIR=$HOME/lamassu-compose
LAMASSU_VDMS_DIR=$HOME/lamassu-virtual-dms
  1. Clone the repository and get into the directory:

    git clone https://github.com/lamassuiot/lamassu-virtual-device.git
    cd lamassu-virtual-device


  2. Basic Virtual Device configuration:

    2.1 Specify the directory where enrolled device certificates (and keys) are stored:

    export VDEV_DEVICE_CERTIFICATES_DIR=$LAMASSU_VDMS_DIR/device-certificates

    2.2 Specify the URL pointing to the EST server:
    export VDEV_EST_SERVER_URL=dev.lamassu.io/api/devmanager

    2.3 Specify the public certificate used by the EST server:
    export VDEV_EST_SERVER_CERT=$LAMASSU_COMPOSE_DIR/tls-certificates/downstream/tls.crt


  3. Optional - Configure the device to connect to AWS IoT core: 3.1 Define the AWS IoT core endpoint to be used. Replace the xxxxxx with the appropriated value as well as the AWS Region to be used:

    VDEV_AWS_IOT_CORE_ENDPOINT=xxxxxx-ats.iot.eu-west-1.amazonaws.com


  4. Run the Virtual Device:

    ./run.sh
